5–4 869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
LAST TRIP DATA CHAPTER 5: STATUS
Last Trip Data
There is no Enabling/Disabling of this feature. It is always ‘ON’.
Path:
Status > Last Trip Data
CAUSE
Range: Off, any FlexLogic Operand
Default: No trip to Date
EVENT
Range: 0 to 4294967295 in steps of 1
Default: 0
DATE
Range: MM/DD/YYYY HH:MM
Default: 01/01/08 00:00:00
PARAMETER 1 to 64
Range: -2147483648 to 2147483647 in steps of 1
Default: 0
Arc Flash
Path: Status > Arc Flash > Arc Flash 1
The status value shows the state of the given Flex operand related to Arc Flash protection.
Light 1(4) PKP
Range: ON, OFF
HS Phase IOC PKP A/B/C
Range: ON, OFF
HS Ground IOC PKP
Range: ON, OFF
Arc Flash OP
Range: ON, OFF
Contact Inputs
Path: Status > Contact Inputs
The status of the Contact Inputs is shown here (see device menu via the menu path). The
‘Off/On’ display indicates the logic state of the Contact Input.
