5–10 869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
INFORMATION CHAPTER 5: STATUS
Information
Path: Status > Information
The Information pages display fixed device information. the pages are divided into three
sections: Main CPU, Comms CPU, and Hardware Versions.
Main CPU
The Information related to the Main CPU is displayed here.
Path:
Status > Information > Main CPU
• Hardware Revision: The hardware revision of the relay
• Firmwar
e Version: The firmware version of the Main CPU
• Boot: The boot code v
ersion of the Main CPU
• Firmwar
e Date: The Main CPU firmware build date in the format mm/dd/yyyy
• Firmwar
e Time: The Main CPU firmware build time
• Boot Dat
e: The Main CPU boot code build date in the format mm/dd/yyyy
• Boot T
ime: The Main CPU boot code build time
• Pr
oduct Serial #: The relay serial number
• Or
der Code: The installed Order Code
• MA
C Address 1: The MAC address for copper Ethernet port 1
• CANBUS R
MIO: The commissioned value of the CANBUS IO is displayed here. If the
relay has never been commissioned then the value will be None, i.e. default=None and
Range=6 alphanumeric characters.
• RMIO R
TDs: The number of remote RTDs detected
Comms CPU
The Information related to the Comms CPU is displayed here.
Path:
Status > Information > Comms CPU
• Comms CPU fw Version: The firmware version of the Comms CPU
• Boot: The boot code v
ersion of the Comms CPU
• Comms
CPU Firmware Date:
The Comms CPU firmware build date in the format mm/dd/yyyy
• Comms
CPU Firmware Time: The Comms CPU firmware build time
• Boot Dat
e: The Comms CPU boot code build date in the format mm/dd/yyyy
• Boot T
ime: The Main CPU boot code build time
• MA
C Address 1: The MAC address for Ethernet port 4
• MA
C Address 2: The MAC address for Ethernet port 5
