B–2 869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
REVISION HISTORY CHAPTER B: APPENDIX B
Major Updates
Table 2: Major Updates for 869-A7
PAGE
NUMBER
(A6
PAGE
NUMBER
(A7)
CHANGES
Manual revision number from A6 to A7, and Product version
revision from 1.6x to 1.7x
1-7 1-8 Revised 869 Order Code information
1-21 1-21
Changed Time Delay to 200,000,000 ms for
Int
roduction>Specifications>User-Programmable
Elements>FlexCurves
2-9 210-
Replaced Typical Wiring diagram (
892824A3.cdr) with new
Typical Wiring diagram 892769A1.pdf
4-, 5-, 6-,
7-
4-, 5-, 6-,
7-
Removed the HMIs associated with the path descriptions in
ea
ch chapter
- 4-7 Added new Custom Configuration section to Setpoints>Device
- 4-44
Added new Remote Modbus Device section to the
Setpoint
s>Communications
4-34 4-31
Replaced single communications card option with two
comm
unications card options for "S" and "C" in Setpoints >
Device > Communications > Ethernet Ports
- 4-61
Updated Setpoints>Device>Installation to add Voltage Cutoff
and Curr
ent Cutoff settings
4-143 4-133
Revised the Current unbalance section to include the inverse
cur
ves
- 4-144
Added new Loss of Excitation to section
Setpoints>Pr
otection>Motor
4-163 4-167
Removed the "Time" setting from the "Speed2 Acceleration"
element found under
Protection>Motor section
4-163 4-159
Removed the "Time" setting from the "Acceleration Time"
element found under
Protection>Motor section
- 4-283
Added Power Factor feature for swing in/out versus lead/lag in
Setpoint
s>Monitoring>Functions
- 4-236
Added new Volts per Hertz section to
Setpoints>Pr
otection>Voltage Elements
- 4-65
Added the "Max. Acceleration Time" and "Speed2 Max. Accel.
T
ime" settings to the System>Motor>Setup section
- 4-233
Added new Out-of-Step section to
Se
tpoints>Protection>Impedance Elements
- 4-317 Added new RTD Trouble section to Setpoints>Monitoring
- 4-319
Added new Loss of Communications section to
Setpoint
s>Monitoring
- 4-306 Added new Speed section to S
etpoints>Monitoring
4-352 4-352 Updated the FlexLogic Operands table
