CHAPTER 5: STATUS OUTPUT RELAYS
869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 5–5
Output Relays
Path:
Status > Output Relays
The status of all output relays is shown here, see above. In the “ITEM NAME” column, the
value indicates the label on the output terminal. The value column indicates the present
ON or OFF state of the output relay.
Virtual Inputs
Path:
Status > Virtual Inputs
The state of all virtual inputs is shown here, see next figure. The value for each Virtual Input
is shown on the control panel graphically as a toggle switch in either the On (|) state or the
Off (O) state.
Figure 5-2: Status of Virtual Inputs
