CHAPTER 6: METERING POWER DEMAND
869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 6–17
Power Demand
Path: Metering > Power Demand 1
Reset (Reset Dmd Date/Time) MM/DD/YY 00:00:00
Real Demand (Real Dmd)
Range: 0.0 k
W to 214748364.7 kW
Maximum Real Demand (Max Real Dmd)
Range: 0.0 kW to 214748364.7 kW
Date/Time Real Demand (Date/Time Real Dmd) MM/DD/YY 00:00:00
Reactive Demand (Reactive Dmd)
Ran
ge: 0.0 kvar to 214748364.7 kvar
Maximum Reactive Demand (Max Reactive Dmd)
Range: 0.0 kvar to 214748364.7 kvar
Date/Time Reactive Demand (Date/Time Reactive Dmd) MM/DD/YY 00:00:00
Apparent Demand (Apparent Dmd)
Ran
ge: 0.0 kVA to 214748364.7 kVA
Maximum Apparent Demand (Max Apparent Dmd)
Range: 0.0 kVA to 214748364.7 kVA
Date/Time Apparent Demand (Date/Time Appar
ent Dmd) MM/DD/YY 00:00:00
Directional Power
Path: Metering > Directional Power
The effective operating quantities of the sensitive directional power elements are displayed
here. The display may be useful to calibrate the feature by compensating the angular
errors of the CTs and VTs with the use of the RCA and CALIBRATION settings.
Directional Power 1 (Directional Power 1)
Range: -214748364.8 kW to 214748364.7 kW
Directional Power 2 (Directional Power 2)
Range: -214748364.8 kW to 214748364.7 kW
Arc Flash
Path: Metering > Arc Flash > Arc Flash 1
HS Phase Current A/B/C
Range: 0.00 to 120000.00 A in steps of 0.01
HS Ground Current
Range: 0.00 to 120000.00 A in steps of 0.01
