7–2 869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
TRANSIENT RECORDS CHAPTER 7: RECORDS
Transient Records
PATH:
RECORDS > TRANSIENTS > TRANSIENT RECORDS
Select the record from which you would like to read the values then click the “Launch
Viewer” button to view the waveform.
Fault Reports
The latest fault reports can be displayed.
Path:
Records > Fault Reports
NUMBER OF REPORTS
This value shows the number of reports since the last clear.
LAST TRIP DATE/TIME
Range: MM/DD/YY/ HH:MM:SS
This value is the date and time on which the last report was generated.
LAST CLEAR DATE/TIME
Range: MM/DD/YY/ HH:MM:SS
This value is the date and time on which the record was cleared.
FAULT REPORT X TIME
Range: MM/DD/YY/ HH:MM:SS
This value is the date and time on which the specified fault report was generated.
Data Logger
The 869 Data Logger record can be retrieved and seen from this window. It displays the
oldest and newest timestamps, and the total number of samples captured for all channels
programmed in Setpoints > Device > Data Logger menu.
Path:
Records > Data Logger
