| CARDIOHELP System | 1 General Information | 11 |
Service Manual | 3.3 | EN | 05
Copyright Maquet Cardiopulmonary GmbH
[MECC] Switch to the thApp MECC
[v-v ECLS] Switch to the thApp v-v ECLS
[PALP] Switch to the thApp PALP
Symbol name [Power
supply status]
Description
[Battery operation] Battery operation; sufficient battery capacity.
[Mains operation] Mains operation.
[Disconnected from ex-
ternal power supply]
CARDIOHELP disconnected from external power supply.
[No battery] No battery available.
[Calibration required] Calibrate the batteries.
1.6 Abbreviations
Abbreviation Explanation
CAN Asynchronous, serial bus system
(Controller Area Network)
CPU Central Processing Unit
CT Computer Tomography
ECC Extra Corporeal Circulation
ELS Emergency life support
FW Firmware (embedded software)
Hall Sensor Sensor for measurement of magnetic fields and electricity
Hb Hemoglobin
Hct Hematocrit
HMI Human Machine Interface
