| CARDIOHELP System | 9 Diagrams | 139 |
Service Manual | 3.3 | EN | 05
Copyright Maquet Cardiopulmonary GmbH
9.1.3 Battery PCB
Battery PCB (front side)
1
2
X1
1
X2
Date:Dat
19.3.10
MAQUET CARDIOPULMONARY
Version:
M300-0006-F00
Battery PCB (back side)
X1 Battery data
X2 Battery power
9.1.4 Power Supply PCB
X1
X2
X3
Power supply PCB
X1 AC input 100 ... 240 VAC
X2 not used
X3 DC output 24 VDC
