Hitachi PXR-D User Manual

6-20 ● Transmission Sequences
1-byte mode ASCII ASCII ASCII
2-byte 2-byte 2-byte
code code code
2-byte mode ASCII
2-byte 2-byte 2-byte 2-byte 2-byte
code code code code code
DLE Item number Printings DLE
Item number
DLE Item number Printings (10 digits max.)
¡ The order of print items is indicated below.
6.4.2 Printings Transmission
6.4.2-1 Text
(1) When printings are to be changed
(2) When all 10 digits of printings are to be invalidated
DLE Item number
(3) When multiple printings are to be designated
Printings change
Printings erasure
¡Multiple print items can be consecutively transmitted within one session.
¡
Print items are to be designated by specifying the item numbers. The item
numbers need not be sorted
6.4.2-2 Item number
Item number 1 2 … 10 … 24 25 … 100
Code (31)H (32)H … (3A)H … (48)H (49)H … (94)H
The parenthesized value positioned to the left of H is a hexadecimal number.
: Enabled when the print item count addition option is employed.
6.4.2-3 Printings
¡An array of "character codes" which consist of 10 or fewer digits.
¡
When the number of digits is less than 10, the IJ printer adds NUL to the end of the
array for interpretation purposes.
¡The coding system varies with the mode which is designated by the "Number of
communication bytes" setting entered form the communication environment setup
screen.
(3-column example) Circled number: Item number
1st column 2nd column
［ 1 ］［4 ］
［ 2 ］［5 ］
［ 3 ］［6 ］
User pattern
Number of Alphanumerical
Dedicated
communication characters and
characters
bytes symbols
Katakana
(00〜47)(48〜127)
Punctuation
mark
