6-50 ● Communication Monitor Function
Item Description
Trans.
External device
→
IJ printer: R (Receive)
IJ printer
→
external device: S (Send)
Communication Sended/received data are displayed in hexadecimal
description notation. Sixteen bytes of data are displayed per line.
Proc. status
The current status is indicated (monitoring or interrupted).
¡ The contents of serial communications between the external device and IJ printer are
displayed.
¡ Up to 1500 bytes of data can be acquired at a time.
¡When you press the Start key, the system erases monitored data and acquires new data.
Item Description
Start
Starts exercising the line monitor function. Erases the
monitored information.
Abort Aborts the execution of the line monitor function.
This switches over whether the system is to detect error-
ridden locations.
¡ Disable: The system will not detect error-ridden
locations.The system will memorize up to
Error detection bytes 1,500 of data transmitted and received.
¡ Enable: The system will display error-ridden locations
in ed. The system will memorize up to
transmitted and received data up to the
location where an error was detected.
Previous list/
Used to switch to another screen when the amount of
Next list
information to be displayed is too large to fit on a single
screen.
Back Returns you to the maintenance menu.
6.6 Communication Monitor Function
(1) Screen display
(2) Input keys
Trans.
R
Communication description
No
1
2
3
4
5
6
7
Comm. monitor
2011.07.07 12:45
Back
Prev.
list
Next
list
S
R
S
R
S
R
05
06
02 10 31 41
32 33 34 35
06
05
06
02 10 31 41
32 33 34 35
42 43 44 45
00 00 00 00
42 43 44 45
00 00 00 00
00 00 00 00
00 03
00 00 00 00
00 03
00 10 32 31
00 AB 32 31
Proc. status: Halted
Abort
Start
Manual
Status:Ready Com=1
Blue:DLE(10), ESC(1B) Red: Failed line.
S158
Error
detection
Start
up
Shut
down
Comm
On/Off
Detection [ 0 ] (0: disable 1: enable )
