IBM 6400 Programmer's Reference

Graph ics Co mm an d Set
Table 86 (Page 2 of 2). Set Extended Color
Byte Value Description Error Code
2
X'0000'
X'0007'
X'0008'
X'FF00'
X'FF07'
X'FF08'
Extended Color
Drawing default
White
Black
Drawing default
Printer default (Black)
Color of Medium
X'0300..04'
For all color selections except the color of the medium, graphics prints in the
selected color. These selections overpaint previous graphics (if of a different
color) by changing the color of the dots to be printed. For a color of medium
selection, following graphics overpaints previous graphics by deleting (erasing)
the dots to print.
Set Fractional Line Width
Description: The Set Fractional Line Width order sets the line width attribute.
This order changes only the line width attribute. The printer uses the last line
width received, no matter which order, Fractional Line Width Order or Set Line
Width, sets the line width. Parameters P1 and P2 form a two byte sequence that
specifies the line width, as follows:
11 L1 P1 P2
Table 87. Set Fractional Line Width
Byte Value Description Error Code
0 X'11' Order code
1 X'02' Length X'0300..03'
2-3
X'0000'
X'0001'-X '017F'
X'0180'-X 'FFFF'
Fractional Line Width
Current default
1 Pel Wide
2 Pels Wide
X'0300..04'
X'0300..0E'
This order aids graphics interchange capability. See also “Set Line Width” on
page 114.
Set Line Type
Description: The Set Line Type order sets the value of the current line type
attribute. This order does not change any other graphics drawing order
attributes.
Parameter P1 specifies the type of line for the graphics output. The following
values are valid for P1:
18 P1
Table 88 (Page 1 of 2). Set Line Type
Byte Value Description Error Code
0 X'18' Order code
Chapter 3. IPDS Commands Reference 113
