IBM 6400 Programmer's Reference

Bar Code Command Set
Set Pattern Set
Description: This order sets the shading pattern attribute for subsequent area
shading. For additional information, see “Begin Area” on page 98 and “End
Area” on page 3-132.
Parameter P1 sets pattern attribute.
08 P1
Table 92. Set Pattern Set
Byte Value Description Error Code
0 X'08' Order code
1 X'00' Drawing Default X'0368..03'
Set Pattern Symbol
Description: This order sets the value of the current shading pattern attribute
for subsequent area shading. For additional information, see “Begin Area” on
page 98 and “End Area” on page 3-132.
Parameter P1 specifies the pattern attribute value. This value determines which
particular pattern from the pattern symbol set the printer uses to shade (fill) the
interior of subsequent areas. The pattern attribute values are:
28 P1
Table 93. Set Pattern Symbol
Byte Value Description Error Code
0 X'28' Order code
1
X'00'
X'01'-X'08 '
X'09'
X'0A'
X'0B'
X'0C'
X'0D'
X'0E'
X'0F'
X'10'
X'40'
Pattern Symbol ID
Use Drawing default
Decreasing Density
Vertical Lines
Horizontal Lines
Diagonal Lines 1 (Bot L/Top R)
Diagonal Lines 2 (Bot L/Top R)
Diagonal Lines 1 (Top L/Bot R)
Diagonal Lines 2 (Top L/Bot R)
No Shading
Solid Shading
Blank
X'0368..04'
Bar Code Command Set
The bar code command set contains the commands and controls for presenting
bar code information on a logical page, a page segment, or an overlay area on
the physical medium. The following commands are the bar code command set:
116 6400 IPDS
