IBM 6400 Programmer's Reference

Bar Code Command Set
Bar Code Output Control (BCOC)
The Bar Code Output Control structured field is the second structured field in the
DATA portion of the Write Bar Code Control command. This structured field
specifies the mapping option for the bar code object. This structured field is
optional and may not be present in the Write Bar Code Control command. The
format of the BCOC field is:
BCAP BCOC BCDD
Length ID Data
Table 96. Bar Code Output Control
Data Area Value Description Error Code
0-1 X'0010'-X'xxxx' Length of Bar Code Output Control (BCOC) X'0202..05'
2-3 X'A66B' Structured Field ID X'020B..05'
4
X'00'
Unit Base (Measurement Units)
Unit Base is 10 Inches
X'0205..05'
5-6
X'3840'
X'0960'
L-Units per Unit Base
14400 L-units per 10 inches
2400 L-units per 10 inches
X'0206..05'
7-8 X'0001' -X'7FFF'
X'FFFF'
X Extent of Bar Code Object in L-units
See “Notation Conventions” on page 27
Use Logical Page Descriptor Value
X'0207..05'
9-10 X'0001' -X'7FFF'
X'FFFF'
Y Extent of Bar Code Object in L-units
See “Notation Conventions” on page 27
Use Logical Page Descriptor Value
X'0207..05'
11 X'30' Mapping Control Option (Position) X'0208..05'
12-13 X'8000' -X'7FFF' X Offset L-units See “Notation Conventions” on
page 27
X'0209..05'
14-15 X'8000' -X'7FFF' Y Offset L-units See “Notation Conventions” on
page 27
X'0209..05'
16-n Ignored
Figure 23 shows the BCOC field specifying the size of the bar code object on the
logical page.
120 6400 IPDS
