Device Control Command Set
Table 27. Exception Handling Control
Byte Value Description Error Code
0-1 X'F600' Exception Handling Control (EHC)
2
Bit 0 0
1
Bit 1 0
1
Bits 2-5 00
Bit 6 0
Bit 7 0
1
Exception Reporting
Do not Report Undefined Character Check
Report Undefined Character Check
Do not Report Page Position Check
Report Page Position Check
Reserved
Position Check Highlighting (Ignored)
Do not Report All other Exceptions with AEA's
Report All other Exceptions with AEA's
3
Bits 0-6 0
Bit 7 0
1
Alternate Exception Actions
Reserved
Take AEA (if defined)
Don't take AEA
4
Bits 0-5 0
Bit 6 0
1
Bit 7 0
1
Exception Presentation Processing
Reserved
No Page Continuation
Page Continuation Action
No Independent Exception Page Print support
Discard Page
Print to point of Exception
(Process limits may apply)
Note: Control of highlighting is not supported.
Print Quality Control (PQC)
The Print Quality Control subcommand allows the host to specify the desired
print quality without changing fonts (see notes). The quality selection (from the
PQC subcommand) specifies the quality for printing text associated with fonts
selected by the Set Coded Font Local (SCFL) command and defined by the Load
Font Equivalence (LFE) command. A PQC specifying a print quality compatible
with the desired font should precede the SCFL command.
The PQC affects only the presentation of page data, and it has no effect in either
of the following cases:
•
When the default font (defined by the offline operator panel selection) is in
use.
•
When downloading resources such as overlays or page segments.
Table 28. XOA Print Quality Control
Byte Value Description Error Code
0-1 X'F800' Print Quality Control (PQC)
2
X'01' -X'55'
X'56' -X'AA'
X'AB' -X'FE'
X'FF'
Print Quality Level
Draft (Low Density Bar Code / Image / Graphics)
DP (High Density Bar Code / Image
(Medium Density Graphics)
NLQ (High Density Bar Code / Image / Graphics)
Depends on Op Panel Setting
X'0292..02'
Chapter 3. IPDS Commands Reference 49
