Device Control Command Set
Logical Page Descriptor (LPD)
Length D6CF Flag Correlation ID
(Optional)
DATA
This command establishes the print characteristics for the logical page. The
Logical Page Descriptor command is only valid in the home state. See “XOH Set
Media Size (SMS)” on page 51 for physical medium size information.
The format of the data field (DATA) for this command is:
Before the printer can present a page of data it must know the following:
•
The units in which distances have been measured
•
The boundaries of the logical page
•
Initialization values for control parameters (margins, line spacing, and so on)
The controls established in a Logical Page Descriptor command remain in effect
until the next Logical Page Descriptor is received unless superseded by explicit
controls in other commands (see “Write Text (WT)” on page 62). In any case,
the latest LPD control values are restored with each Begin Page or Begin
Overlay command.
The LPD command is valid with 24, 28, 34, 36, 38, 40, 41 or 43 bytes. The 64XX
accept the LPD command using any of these valid lengths.
Table 14 (Page 1 of 2). Logical Page Descriptor
Byte Value Description Error Code
0
X'00'
Unit-Base (Measurement Units)
10 inches
X'0264..02'
1 Reserved
2-3
X'3840'
X'0960'
X and I L-units per unit base
14400 L-units per 10 inches
2400 L-units per 10 inches
X'0260..02'
4-5
X'3840'
X'0960'
Y and B L-units per unit base
14400 L-units per 10 inches
2400 L-units per 10 inches
X'0261..02'
6 Reserved
7-9 X'000001' -
X
'007FFF'
X-Extent of logical page (Width). See “Notation
Conventions” on page 27
X'0262..02'
10 Reserved
11-13 X'000001' -
X
'007FFF'
Y-Extent of logical page (Length) See “Notation
Conventions” on page 27
X'0263..02'
14 Reserved
15
Bit 0 0/1
Bits 1-7 0000000
Ordered Data Flag Bit
Order Page = 1
Reserved
16-23 Reserved
24-25
X'0000'
X'5A00'
X'FFFF'
I-Axis Orientation
0 Degrees
180 Degrees
Printer Default
X'0268..02'
Chapter 3. IPDS Commands Reference 39
