IBM 6400 Programmer's Reference

Presentation Text Command Set
Table 57 (Page 2 of 2). Overstrike
Byte Value Description Error Code
4
Bits 0-3
Bit 4 0
1
Bit 5 0
1
Bit 6 0
1
Bit 7 0
1
Bypass Identifiers
Reserved
Overstrike white space from
Relative Move Inline
Bypass white space from
Relative Move Inline
Overstrike white space from
Absolute Move Inline
Bypass white space from
Absolute Move Inline
Overstrike white space from Space
or Variable Space Character
Bypass white space from Space
or Variable Space Character
Bypass Treat Bits 0-6 according
to their set values
No Bypass Treat Bits 0-6 as if
their values are set to zero
5 Ignored
6 X'00' -X'FF' Overstrike Character
Relative Move Baseline (RMB)
This control moves the baseline coordinate relative to the current baseline
coordinate position.
Note: Baseline displacement values that require a negative baseline
displacement in order to print results in an error if the LPD command specifies
ordered printing.
Table 58. Relative Move Baseline
Byte Value Description Error Code
0-1 X'2BD3' Text Control Escape Sequence
2 X'04' Length X'021E..01'
3
X'D4'
X'D5'
Relative Move Baseline
Unchained
Chained
4-5 X'8000' -X'7FFF' Increment (Br) See “Notation Conventions” on
page 27
Relative Move Inline (RMI)
This control moves the inline coordinate of the presentation position relative to
the current inline position. Negative values are in twos-complement form.
Notes:
1. Values as large as X
'FFFF' are valid but might be off the page
2. Several Relative Move Inline controls used in a single line reduce
throughput. If possible, replace Relative Move Inline controls with spaces, or
combine multiple sequential Relative Move Inline controls into a single
Relative Move Inline control.
Chapter 3. IPDS Commands Reference 69
