Page Segment Command Set
Note: Negative values must be specified in twos-complement form.
Table 105 (Page 2 of 2). Data Field-Include Overlay Command
Byte Value Description
3-5
000000 - 007FFF
FF8000 - FFFFFE
FFFFFF
X Coordinate
Positive Offset Value Relative to the Logical Page
Negative Offset Value Relative to the Logical Page
Use the Current Inline Text Position
6 00 Reserved
7-9
000000 - 007FFF
FF8000 - FFFFFE
FFFFFF
Y Coordinate
Positive Offset Value Relative to the Logical Page
Negative Offset Value Relative to the Logical Page
Use the Current Baseline Text Position
Page Segment Command Set
The page segment command set contains the commands that the printer uses to
store, delete, and present information in the page segment memory of the
printer. These commands are independent of any specific data types defining
the page segment. The following commands are the page segment command
set:
The following pages describe the page segment command set commands.
Table 106. Page Segment Command Set Commands
Name Command Sub-
command
Description
Begin Page
Segment
X'D65F'
Deactivate Page
Segment
X'D66F'
Include Page
Segment
X'D67F'
Begin Page Segment (BPS)
Length D65F Flag Correlation ID (Optional) DATA
The Begin Page Segment command causes the printer to enter the page
segment state. This command is only valid in the home state. Receipt of an End
Page command while in the page segment state causes the printer to return to
the home state.
The Page Segment command defines a segment of page data to save within the
printer for later printing. This printer later includes this segment when it
receives the Include Page Segment command.
The DATA field is two bytes in length and can be any value between
X
'01' and X'7F'. This value is the page segment identifier. If this value
specifies a page segment identifier already loaded in the printer, an exception
occurs.
132 6400 IPDS
