Icom IC-7000 Instruction Manual

104
8
MEMORY OPERATION
8
q Push [PBT/M-ch/RIT] momentarily to select the M-
ch/RIT function, if the twin PBT is selected.
•[PBT/M-ch/RIT] indicator (Green) goes out.
w Select the menu
M
- 2
.
e Push [F-4
V/M
] to select memory mode, then se-
lect the desired memory channel with [M-ch].
•Memory channel contents appear instead of the VFO’s
frequency readout.
r Set the desired frequency and operating mode.
•To program a blank channel, push [
Y
( BAND )] or
[
Z
(
BAND )] to select the desired band or use direct fre-
quency entry with the keypad (HM-151).
t Push [F-2
MW
] for 1 sec. to program the displayed
frequency and operating mode into the memory
channel.
[EXAMPLE]: Programming 21.280 MHz/USB into
ch 18.
Push for
1 sec.
MW
[MENU/GRP]
[PBT/M-ch/RIT] indicator
[PBT/M-ch/RIT] switch/[M-ch] (inner) control
[F-2] [F-4]
[Y]
[Z]
D Programming in memory mode

Icom IC-7000 Specifications

General

Input voltage	13.8 V
Microphone included	Yes
Product type	Portable CB radio
Product color	Black
Housing material	-
Frequency range	0.5 - 455000 MHz
Channels quantity	503 channels

Weight and Dimensions

Depth	180 mm
Width	167 mm
Height	58 mm
