Icom IC-7000 Instruction Manual

32
3
BASIC OPERATION
3
• [TS] switch flow chart
SSB/CW/RTTY modes Any mode FM/WFM/AM modes
1 Hz tuning
10 Hz tuning
momentarily momentarily
1 MHz tuning
Programmable step tuning
(100 Hz –100 kHz)
momentarily
PushPush
Push Push
1 sec.1 sec.
1 sec.
Selectable for each mode.
Appears Appears
Appears
D
1
⁄
4 tuning function (CW/RTTY only)
While operating in CW/RTTY, the
1
⁄4 tuning function is
available for critical tuning. Dial sensitivity is reduced
to
1
⁄4 of normal when the
1
⁄4 function is in use.
q Select
M
- 3
.
w Push [F-2
1/4
] to toggle the
1
⁄4 function ON and
OFF.
• “ ” indication appears when the function is in
use.
[MENU/GRP] [F-2]
Appears
•Push and hold [MENU/GRP] for 1 sec. once or twice
to select the menu group
M
.
•Push [MENU/GRP] momentarily one or more times to
select the menu
M
- 3
.

Icom IC-7000 Specifications

General

Input voltage	13.8 V
Microphone included	Yes
Product type	Portable CB radio
Product color	Black
Housing material	-
Frequency range	0.5 - 455000 MHz
Channels quantity	503 channels

Weight and Dimensions

Depth	180 mm
Width	167 mm
Height	58 mm
