PANEL DESCRIPTION
1
D Menu S-3 functions
MEMORY WRITE (pgs. 103, 104)
Push and hold for 1 sec. to store the dis-
played VFO frequency and operating
mode into the selected memory channel.
MEMO PAD WRITE (p. 111)
Push to store the displayed VFO fre-
quency and operating mode into a memo
pad.
MEMO PAD READ (p. 112)
Push to call up a memo pad.
✔
What is the memo pad function?
The memo pad function stores the frequency and operating
mode for easy recall. The memo pads are separate from the
usual memory channels. The default number of memo pads
is 5, however, this can be increased to 10 in the miscella-
neous (others) set mode, if desired. (p. 134)
D Menu G-1 (Scope) functions
SWEEP STEPS (pgs. 72, 73)
➥ Push momentarily to change the sweep
step size.
•Available steps are ±10, 25, 50, 100 and 250
kHz.
➥ Push and hold for 1 sec. to change the
sweep steps to ±10 kHz.
PEAK HOLD (pgs. 72, 73)
➥ Push to freeze the current simple band
scope display.
•“H” indicator appears while the function is in
use.
➥ Push and hold for 1 sec. to clear the peak
levels.
•Peak levels are displayed in the background
on the simple band scope display. The peak
hold function can be disabled in the scope
set mode. (p. 73)
FIX/CENTER SELECTION (pgs. 72, 73)
➥ Push to toggle the simple band scope fix
mode and center mode.
•Fix mode:
Rotating [DIAL] leaves the marker centered.
•Center mode:
Rotating [DIAL] moves the edge frequencies.
➥ While fix mode operation, push and hold
for 1 sec. to set the displayed frequency
to that of the marker.
SWEEP SPEED
➥ Push momentarily to change the sweep
speed between Fast and Slow. (pgs. 72,
73)
➥ Push and hold for 1 sec. to enter the
scope set mode. (p. 73)
