Icom IC-7000 Instruction Manual

D VOX set mode
86
6
FUNCTIONS FOR TRANSMIT
6
3.
VOX Delay
This item adjusts the VOX (Voice-activated Transmit)
delay time. The delay time can be adjusted from 0 to
2.0 sec. in 0.1 sec. steps.
•Push [F-4
DEF
] for 1 sec. to return to default delay time.
  0 . 2 s
0.2 sec. (default)
1.
VOX Gain
This item adjusts the VOX gain for the VOX (voice ac-
tivated transmit) function.
This setting can be adjusted
from 0 to 100% in 1% steps.
•Push [F-4
DEF
] for 1 sec. to return to default gain.
  5 0 %
50% (default)
2.
Anti-VOX
This item adjusts the ANTI-VOX gain for the VOX
(voice activated transmit) function.
This setting can be
adjusted from 0 to 100% in 1% steps.
•Push [F-4
DEF
] for 1 sec. to return to default gain.
  5 0 %
50% (default)
■ Transmit filter width setting (SSB only)
The transmit filter width for SSB mode can be se-
lected from wide, middle and narrow.
q Select an SSB mode (USB or LSB) with [MODE].
w Select
M
- 3
.
e Push and hold [F-4
TBW
] for 1 sec. once or twice
to select the desired transmit filter width from nar-
row, middle and wide.
•Push [F-4
TBW
] momentarily to indicate the selected
TX filter width.
•The transmit filter width window appears for showing
the selected TX filter width each time [F-4
TBW
].
•The following filters are specified as the default. Each
of the filter widths can be set in the quick set mode.
(pgs. 123, 124)
WIDE : 100 Hz to 2900 Hz
MID : 300 Hz to 2700 Hz
NAR : 500 Hz to 2500 Hz
•Push and hold [MENU/GRP] for 1 sec. once or twice
to select the menu group
M
.
•Push [MENU/GRP] momentarily one or more times to
select the menu
M
- 3
.
[MENU/GRP] [F-4]

Icom IC-7000 Specifications

General

Input voltage	13.8 V
Microphone included	Yes
Product type	Portable CB radio
Product color	Black
Housing material	-
Frequency range	0.5 - 455000 MHz
Channels quantity	503 channels

Weight and Dimensions

Depth	180 mm
Width	167 mm
Height	58 mm
