PANEL DESCRIPTION
■ Multi-function keys
D Menu M-1 functions
SPLIT OPERATION
➥ Push momentarily to toggle the split func-
tion ON and OFF. (p. 91)
• “”and transmit frequency appear when
the split function is ON.
➥ Push and hold for 1 sec. to turn the quick
split function ON. (p. 92)
•The offset frequency must be programmed in
advance using the miscellaneous (others) set
mode. (p. 131)
•The offset frequency is shifted from the dis-
played frequency.
•The quick split function can be turned OFF in
the miscellaneous (others) set mode. (p. 131)
VFO A/B SELECTION
➥ Push momentarily to exchange the trans-
mit VFO and receive VFO contents. (p.
27)
➥ Push momentarily to toggle the transmis-
sion VFO and reception VFO during split
operation. (p. 91)
➥ Push momentarily to toggle the transmit
and receive frequencies (and modes) of
memory channels when the split function
is turned ON.
➥ Push and hold for 1 sec. to equalize the
frequency and operating mode of the two
VFO’s.
•The lower indicated frequency and operating
mode are equalized to the upper (indicated)
VFO frequency and operating mode.
FILTER SELECTION (p. 77)
➥ Push momentarily to select one of three
IF filter settings.
➥ Push and hold for 1 sec. to enter the filter
set mode.
TRANSMIT FREQUENCY CHECK (pgs. 65, 91)
Monitors the transmit frequency when
pushed and held.
•While pushing this key, the transmit fre-
quency can be changed with [DIAL].
D Menu M-2 functions
MEMORY MENU (p. 105)
Push momentarily to indicate the memory
frequency and modes.
•Memory list indication is available.
MEMORY WRITE (pgs. 103, 104)
Push and hold for 1 sec. to store the se-
lected readout frequency and operating
mode into the displayed memory channel.
MEMORY CLEAR (p. 108)
Push and hold for 1 sec. to clear the se-
lected memory channel contents.
• “ ” appears.
VFO/MEMORY SELECTION
➥ Push momentarily to toggle VFO and
memory modes. (pgs. 27, 102)
➥ Push and hold for 1 sec. to transfer the
selected memory channel to the currently
displayed VFO. (p. 109)
D Menu M-3 functions
DURING SSB OPERATION:
DURING CW OPERATION:
DURING RTTY OPERATION:
DURING AM OPERATION:
F-1 F-2 F-3 F-4
VOX AGC
F-1 F-2 F-3 F-4
1/4 AGC
F-1 F-2 F-3 F-4
1/4BRK AGC
F-1 F-2 F-3 F-4
TBWVOX COM AGC
F-4
V/M
F-3
MCL
F-2
MW
F-1
MEM
F-1 F-2 F-3 F-4
MWMEM V/M
MCL
F-4
XFC
F-3
FIL
F-2
A/B
F-1
SPL
SPL A/B FIL XFC
F-1 F-2 F-3 F-4
