Icom IC-7000 Instruction Manual

109
8
MEMORY OPERATION
■ Frequency transferring
This is useful for transferring programmed contents to
VFO.
q Select the menu
M
- 2
.
•Push and hold [MENU/GRP] for 1 sec. once or twice
to select the menu group
M
.
•Push [MENU/GRP] momentarily one or more times to
select the menu
M
- 2
.
w Push [F-4
V/M
] momentarily to select the VFO
mode.
e Push [F-1
MEM
] to display the memory channel
contents.
•Memory channel contents appear above the multi-func-
tion key indicator.
r Push [PBT/M-ch/RIT] momentarily to select the M-
ch/RIT function, if the twin PBT is selected.
•[PBT/M-ch/RIT] indicator (Green) goes out.
t Select a memory channel with [M-ch].
•“ ” appears if the selected memory channel is a
blank channel (and does not have contents). In this
case transferring is not possible.
y Push [F-4
V/M
] for 1 sec. to transfer the frequency
and operating mode.
•Transferred frequency and operating mode appear in
the display.
[EXAMPLE]: Transferring contents of memory 16.
Operating frequency
Contents of memory 16
Push for
1 sec.
V/M
: 21.320 MHz/USB (VFO)
: 14.020 MHz/CW
[MENU/GRP] [F-1]
[PBT/M-ch/RIT] indicator
[PBT/M-ch/RIT] switch/[M-ch] (inner) control
[F-4]
D Transferring in VFO mode
The frequency and operating mode in a memory chan-
nel can be transferred to the VFO.
Frequency transferring can be performed in either VFO
mode or memory mode.
Menu group selection
Push [MENU/GRP] for 1 sec.
Selection from:
M
,
S
or
G
(Graphic)
Menu selection (Example: M)
Push [MENU/GRP] momentarily.
Selection from:
M - 1
,
M - 2
or
M - 3
Either
Y or Z
Either
Y or Z

Icom IC-7000 Specifications

General

Input voltage	13.8 V
Microphone included	Yes
Product type	Portable CB radio
Product color	Black
Housing material	-
Frequency range	0.5 - 455000 MHz
Channels quantity	503 channels

Weight and Dimensions

Depth	180 mm
Width	167 mm
Height	58 mm
