D Auto repeater function
65
4
RECEIVE AND TRANSMIT
You may be able to receive the other party’s transmit
signal directly (called ‘listening on the repeater input’)
without having to go through a repeater.
Transmit frequency monitor check (XFC) allows you
to check this.
q Select
M
-
1
.
w While receiving, push and hold [F-4
XFC
] to see if
you can receive the other party’s transmit signal di-
rectly.
•While holding [F-4
XFC
], the offset direction and fre-
quency are displayed above the multi-function key in-
dicator.
D Transmit frequency monitor check
This function automatically activates the repeater set-
tings (DUP– or DUP+ and/or tone encoder ON/OFF)
when the operating frequency falls within the general
repeater output frequency range and deactivates
them when outside of the range.
Set the auto repeater function ON-1 (auto duplex set-
ting) or ON-2 (auto duplex setting and activating tone
encoder) in the miscellaneous (others) set mode in
advance (p. 133). When ON-1 or ON-2 are turned on,
repeater settings are automatically activated accord-
ing to the table below right.
ON-1 sets the duplex setting and ON-2 sets the du-
plex setting and tone encoder automatically.
q Push [AF(
SET
)] momentarily to enter the set mode
menu.
w Push [F-4
OTH
] to enter the miscellaneous (oth-
ers) set mode.
e Push [F-1
≤
] or [F-2
≥
] to select “
Auto Re-
peater
.”
r Rotate [DIAL] to select the desired auto repeater
condition from ON-1, ON-2 and OFF.
•Push [F-4
DEF
] for 1 sec. to return to default setting.
t Push [
Z
(
MENU
/
GRP
)] twice to return to the normal
operating mode.
• Frequency range and offset direction
FREQUENCY RANGE DUPLEX DIRECTION
145.200–145.495 MHz minus duplex
146.610–146.995 MHz minus duplex
147.000–147.395 MHz plus duplex
442.000–444.995 MHz plus duplex
447.000–449.995 MHz minus duplex
