Icom IC-7000 Instruction Manual

138
13
SET MODE
13
■ Miscellaneous (others) set mode (continued)
48
CI-V Baud Rate
This item sets the data transfer rate. 300, 1200, 4800,
9600, 19200 bps and “Auto” are available.
When “Auto” is selected, the baud rate is automati-
cally set according to the connected controller or re-
mote controller.
Auto
Auto baud rate
(default)
19200
19200 bps
49
CI-V Address
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-7000’s address is 70h.
When 2 or more IC-7000’s are connected to an op-
tional CT-17
CI - V LEVEL CONVERTER , rotate [DIAL] to
select a different address for each IC-7000 in the
range 01h to 7Fh.
70h
Address of 70h
(default)
7Fh
Address of 7Fh
50
CI-V Transceive
Transceive operation is possible with the IC-7000 con-
nected to other Icom HF transceivers or receivers.
When “ON” is selected, changing the frequency, op-
erating mode, etc. on the IC-7000 automatically
changes those of connected transceivers (or re-
ceivers) and vice versa.
ON
Transceive ON
(default)
OFF
Transceive OFF
51
REF Adjust
This item adjusts the internal reference frequency
within 0 to 100% range in 1 % steps.
47
Front Keypad Type
This item selects the front keypad type connected to
the [MIC] connector of the controller.
Dot/Dash
Dot/Dash (default)
Ext Keypad
External keypad
