Invacare Pronto M91 Service Manual

SECTION 12—ELECTRONICS
Pronto
®
M91™and M94™ 116 Part No. 1125038
Repositioning the Joystick
ASBA or Adjustable ASBA Model
NOTE:Forthisprocedure,refertoFIGURE 12.4.
1. Turntheleverontheadjustmentlocktoreleasetheadjustmentlockfromjoystick
mountingtube.
2. Removethejoystickfromthewheelchair.
3. Removethethreehexscrewsthatsecurejoystickmountingbracket,thethreadedhole
halfclampandtheopenedholehalfclamptothearmtube.
4. Repositionthethreadedholehalfclampandopenedholehalfclampontheopposite
armtube.Makesurethreadedholehalfclampisontheinsideofarmtube.
5. Whileholdingthetwohalfclamps,installthefronthexscrewintothetwohalfclamps.
Securelytighten.
6. Lineupmountingholesofthejoystickmountingbracketwiththemountingholesin
thetwohalfclamps.
7. Securethejoystickmountingbrackettothetwohalfclampswiththeremainingtwo
hexscrews.
8. Slidetubethroughthebrackettothedesiredposition.
9. Slideadjustmentlockoverendoftubeandsecureadjustmentlocktotubebyturning
leveronadjustmentlock.
NOTE:Ifadjustmentlockdoesnotfitovertube,rotate180°.
FIGURE 12.4 Repositioning the Joystick - ASBA or Adjustable ASBA Model
Van Seat Model
NOTE:Forthisprocedure,refertoFIGURE 12.5onpage117.
NOTE:Takenoteofpositionandorientationofmountinghardwareforreinstallingthejoystick
assembly.
Hex Mounting
Screws
Washer
Adjustment
Lock Lever
Mounting Bracket
Joystick
Mounting Tube
Joystick
Arm Tube
Mounting Bracket
(Threaded Plate)
NOTE:MK
5
SPJ‐80joystick
shown.Allotherjoysticksreposition
thesameway.

Invacare Pronto M91 Specifications

Power and Performance

maximum speed	6.5 mph / 4.5 mph
incline capability	9˚
weight capacity	300 lb. (400 lb. option)

Wheel and Caster Sizes

front casters	6" x 2"
drive wheels	14" x 3"
rear casters	6" x 2"

Weight and Dimensions

length with footboard up	39"
length with footboard down	40" - 42"
width excluding joystick	25.9"
height	37" - 48"
seat width	18" - 22"
seat depth	16" - 20"
overall height	37" - 40"
back height	18"
seat-to-floor height	21" - 23"
weight with batteries	273 lb.
weight without batteries	199 lb.
wheelchair mass	275 lb.
turning radius front	19.5"
turning radius rear	21.5"
ground clearance	3.25"
