Invacare Pronto M91 Service Manual

REFERENCE DOCUMENTS
Pronto
®
M91™and M94™ 2 Part No. 1125038
 WARNING
A QUALIFIED TECHNICIAN MUST PERFORM THE INITIAL SET UP OF THIS
WHEELCHAIR. ALSO, A QUALIFIED TECHNICIAN MUST PERFORM ALL
PROCEDURES IN THE SERVICE MANUAL.
DEALERS AND QUALIFIED TECHNICIANS: DO NOT SERVICE OR OPERATE
THIS PRODUCT OR ANY AVAILABLE OPTIONAL EQUIPMENT WITHOUT
FIRST COMPLETELY READING AND UNDERSTANDING THESE
INSTRUCTIONS AND ANY ADDITIONAL INSTRUCTIONAL MATERIAL SUCH
AS OWNER’S MANUALS, SERVICE MANUALS OR INSTRUCTION SHEETS
SUPPLIED WITH THIS PRODUCT OR OPTIONAL EQUIPMENT. IF YOU ARE
UNABLE TO UNDERSTAND THE WARNINGS, CAUTIONS OR INSTRUCTIONS,
CONTACT A HEALTHCARE PROFESSIONAL, DEALER OR TECHNICAL
PERSONNEL BEFORE ATTEMPTING TO USE THIS EQUIPMENT - OTHERWISE,
INJURY OR DAMAGE MAY OCCUR.
IF WHEELCHAIR IS EQUIPPED WITH POWER TILT ONLY OR THE FORMULA
PTO PLUS SEATING SYSTEM, REFER TO POWER TILT ONLY FOR PRONTO
M71 AND M91 OWNER’S MANUAL, PART NUMBER 1118362 OR TO FORMULA
PTO PLUS POWERED SEATING SERVICE MANUAL, PART NUMBER 1125031
PERFORM THE FOLLOWING PROCEDURES:
• ADJUSTING SEAT HEIGHT
• ADJUSTING SEAT POSITION
• CHARGING THE BATTERIES
 ACCESSORIES WARNING
Invacare products are specifically designed and manufactured for use in conjunction
with Invacare accessories. Accessories designed by other manufacturers have not
been tested by Invacare and are not recommended for use with Invacare products.
REFERENCE DOCUMENTS
Refertothetablebelowforpartnumbersofadditionaldocumentswhicharereferenced
inthismanual.
MANUAL PART NUMBER
M91 Owner’s Manual (before 1/24/06) 1110560
M91 Owner’s Manual (after 1/24/06) 1141450
M91 Owner’s Manual (M91 base w/MK6i™) 1143153
M94 Owner’s Manual 1122145
MK
5
™EX™and MK
5
TT-EX Electronics Manual 1114808
MK
5
NX™Electronics Manual 1110532
MK6i Service Manual 1143203
MK6i Field Reference Guide 1141471
MKIV™ RII Electronics 1095272
NOTE:Updatedversionsofthismanualareavailableonwww.invacare.com.

Invacare Pronto M91 Specifications

Power and Performance

maximum speed	6.5 mph / 4.5 mph
incline capability	9˚
weight capacity	300 lb. (400 lb. option)

Wheel and Caster Sizes

front casters	6" x 2"
drive wheels	14" x 3"
rear casters	6" x 2"

Weight and Dimensions

length with footboard up	39"
length with footboard down	40" - 42"
width excluding joystick	25.9"
height	37" - 48"
seat width	18" - 22"
seat depth	16" - 20"
overall height	37" - 40"
back height	18"
seat-to-floor height	21" - 23"
weight with batteries	273 lb.
weight without batteries	199 lb.
wheelchair mass	275 lb.
turning radius front	19.5"
turning radius rear	21.5"
ground clearance	3.25"
