Invacare Pronto M91 Service Manual

SECTION 7—FOOTBOARD ASSEMBLY
Pronto
®
M91™and M94™ 78 Part No. 1125038
SECTION 7—FOOTBOARD
ASSEMBLY
 WARNING
After ANY adjustments, repair or service and BEFORE use, make sure that all
attaching hardware is tightened securely - otherwise injury or damage may result.
Before performing any maintenance, adjustment or service verify that ON/OFF
switch on the joystick is in the OFF position.
Pinch point may occur when rotating the footboard assembly.
DO NOT stand on the flip-up footboard. When getting in or out of the wheelchair,
make sure that the flip-up footboard is in the upward position.
LIMITED CLEARANCE BETWEEN FOOTBOARD AND CASTER - The user’s feet
MUST remain on the footboard while operating the chair. If the user’s feet are
allowed to rest off the side of the footboard they may come in contact with the
caster possibly resulting in injury.
Removing/Installing the Footboard Assembly
NOTE:Forthisprocedure,refertoFIGURE 7.1onpage79.
Removing
1. Removethequickreleasepinthatsecuresthefootboardassemblytothewheelchair
framebydepressingthebuttonwhileslidingthepinout.
2. Removethefootboardassemblyfromthewheelchairframe.
Installing
 WARNING
Make sure the detent balls of the quick release pin are fully released and protruding
past the outer edge of the tube before operating the wheelchair. Otherwise, injury
and/or damage may result.
Keep detent balls clean.
1. Positionthefootboardassemblyontothewheelchairframesothatthemountinghole
inthewheelchairframealignswiththedesiredmountingholeinthefootboard
assembly.
2. Installthequickreleasepinbydepressingthebuttonwhileslidingthepinin.Ensure
thatthedetentballsofthequickreleasepin
are fullyreleasedandprotrudingpastthe
outeredgeofthetube(Detail“A”ofFIGURE 7.1).

Invacare Pronto M91 Specifications

Power and Performance

maximum speed	6.5 mph / 4.5 mph
incline capability	9˚
weight capacity	300 lb. (400 lb. option)

Wheel and Caster Sizes

front casters	6" x 2"
drive wheels	14" x 3"
rear casters	6" x 2"

Weight and Dimensions

length with footboard up	39"
length with footboard down	40" - 42"
width excluding joystick	25.9"
height	37" - 48"
seat width	18" - 22"
seat depth	16" - 20"
overall height	37" - 40"
back height	18"
seat-to-floor height	21" - 23"
weight with batteries	273 lb.
weight without batteries	199 lb.
wheelchair mass	275 lb.
turning radius front	19.5"
turning radius rear	21.5"
ground clearance	3.25"
