SECTION 4—SEAT
Pronto
®
M91™and M94™ 52 Part No. 1125038
7. Secureeachcrossbartotheseatframewithahexscrewandcovedwasher .Torquethe
hexscrewto75in‐lbs±20%.
8. Ifnecessary,installthenewspreaderbar.RefertoRemoving/InstallingtheSpreader
Baronpage 58.
FIGURE 4.12 Adjusting the Seat Width
Adjusting the Seat Depth
NOTE:Forthisprocedure,refertoFIGURE 4.13onpage 54.
1. Examinethefollowingcharttodetermineifthedesiredseatdepthadjustmentis
withinorbeyondtherangeoftheexistingseatframe.
FRAME SIZE SEAT DEPTH RANGE
SMALL 16 - 19 inches in 1-inch increments
LARGE 19 - 22 inches in 1-inch increments
Side Rail
Crossbar
Crossbar
Mounting Holes
Seat Frame
Hex Screw
Coved
Washer
Seat Frame
Mounting
Hole
NOTE:Seatpan,backand
armsremovedforclarity.
Crossbars
Mounting
Hole
Side Rail
Mounting Hole
Side Rail
Hex Screw
DETAIL “A” - REPLACING THE CROSSBARS
Hex Screw
