Invacare Pronto M91 Service Manual

Typical Product Parameters
Pronto
®
M91™and M94™ 18 Part No. 1125038
Pronto M94
NOTE:Basedon24‐inchwideVanseat.
*NOTE:Valuesforran gear e calculatedformaximumchairweightratingusinglargestbatteries applicable(22NF) ,pertestpr ocedures
describedinANSI/RE SNAWC/VOL2‐1998Section 4and meetfederalreimbursementrequir ementsforthispr oduct .Whileconsidered
typical,theyarederivedbasedoncert ain
idealconditio ns.Varianc esinbatterycondition,userweight,usa gepatternoroverallterrain
conditionswillresultinactualvaluesforrangethatdifferfromthesestatedvalues.
18-INCH
VAN SEAT
20-INCH
VAN SEAT
22-INCH
VAN SEAT
24-INCH
VAN SEAT
ASBA SEAT
SEAT WIDTH RANGE: 18 inches 20 inches 22 inches 24 inches 18 to 24 inches
SEAT DEPTH: 16 to 18 inches 18 to 20 inches 20 to 22 inches 20 to 22 inches 16 to 22 inches
BACK HEIGHT W/O
HEADREST:
SEMI RECLINE:
18 inches 18 inches 18 inches 18 inches 16 to 20 inches
BACK ANGLE RANGE:
SEMI RECLINE:
35° to 115° 35° to 115° 35° to 115° 35° to 115°
Standard
80° to 100°
UPHOLSTERY:
WITH SEAT PAN:
Grey Vinyl Black Nylon Back
SEAT-TO-FLOOR: 21 to 24 inches
(Cushion Not Compressed)
19 to 22 inches
(To Seat Pan)
OVERALL WIDTH
(NO JOYSTICK): 27 to 29 inches
OVERALL HEIGHT: 31 inches (Folded)
54 inches (Upright)
OVERALL LENGTH: 35 inches (With Footboard Folded)
43 inches (With Footboard Extended)
DRIVE WHEELS/TIRES: 14 x 3-inch (Flat Free)
CASTER W/PRECISION
SEALED BEARINGS: 6 x 2-inch Front/Rear
FOOTRESTS/
LEGRESTS:
Flip Up, Depth and Height Adjustable, Footboard,
Swingaway Front Rigging, Elevating Legrest
WEIGHT W/ SEATING
SYSTEM AND
ACCESSORIES:
W/O BATTERIES:
W/BATTERIES:
216 lbs
290 lbs
SHIPPING: 260 lbs (w/o Batteries), 310 lbs (w/Batteries)
ARMRESTS: Adjustable Angle, Height and Width, Desk and Full Length
BATTERIES: 22NF - Quantity 2
PERFORMANCE:
SPEED:
TURNING RADIUS:
*RANGE (VARIABLE):
**WEIGHT LIMITATION:
0 to 4.5 mph
19½ inches
10 to 15 miles
500 lbs

Invacare Pronto M91 Specifications

Power and Performance

maximum speed	6.5 mph / 4.5 mph
incline capability	9˚
weight capacity	300 lb. (400 lb. option)

Wheel and Caster Sizes

front casters	6" x 2"
drive wheels	14" x 3"
rear casters	6" x 2"

Weight and Dimensions

length with footboard up	39"
length with footboard down	40" - 42"
width excluding joystick	25.9"
height	37" - 48"
seat width	18" - 22"
seat depth	16" - 20"
overall height	37" - 40"
back height	18"
seat-to-floor height	21" - 23"
weight with batteries	273 lb.
weight without batteries	199 lb.
wheelchair mass	275 lb.
turning radius front	19.5"
turning radius rear	21.5"
ground clearance	3.25"
