Invacare Pronto M91 Service Manual

SECTION 14—TRANSPORT READY PACKAGE (TRRO)
Pronto
®
M91™and M94™ 124 Part No. 1125038
 WARNING
TRANSPORT READY PACKAGES ARE NOT RETROFITTABLE TO EXISTING
MODELS AND ARE NOT FIELD SERVICEABLE.
Only use the transport brackets included with TRRO and TRBKTS for the purposes
described in this manual.
Battery retention brackets MUST be installed at all times. Otherwise, the wheel-
chair will not be WC/19 compliant. Refer to Installing/Removing the Batteries on
page 103.
About Transport Ready Packages
TRROincludesfourfactory‐installedtransportbracketsandawheelchairanchored
pelvicbelt.TRROhasbeencrash‐testedinaccordancewithANSI/RESNAWCVol1
Section19FrontalImpactTestrequirementsforwheelchairswitha168lbcrashdummy,
whichcorrespondstoapersonwithaweightof114to209lbs.
TRBKTSincludesfourfactory‐installedwheelchairtransportbrackets.TRBKTShasnot
beencrash‐testedinaccordancewithWC19.Usethesetransportbracketsonlytosecure
anunoccupiedwheelchairduringtransport.
Asofthisdate,theDepartmentofTransportationhasnotapprovedanytie‐downsystems
fortransportationofauserwhileinawheelchair,inamovingvehicleofanytype.Itis
Invacare’spositionthatusersofwheelchairsshouldbetransferredintoappropriate
seatinginvehiclesfortransportationandusebemadeoftherestraintsmadeavailableby
theautoindustry.Invacarecannotanddoesnotrecommendanywheelchair
transportationsystems.
Compliance Information
ThiswheelchairconformswiththerequirementsoftheANSI/RESNAWC/Vol.1‐Section
19.
NOTE:ANSI=AmericanNationalStandardsInstitute,RESNA=RehabilitationEngineering
andAssistiveTechnologySocietyofNorthAmerica.
Thiswheelchairhasbeendynamicallytestedinaforward‐facingmodewiththespecified
crashtestdummy,whichcorrespondstoaperson
withaweightof114‐209pounds,
restrainedbyBOTHpelvicandupper‐torsobeltsinaccordancewithANSI/RESNAWC
Vol1Section19.BOTHpelvicandupper‐torsobeltsshouldbeusedtoreducethe
possibilityofheadandchestimpactswithvehiclecomponents.
Specifications
MODEL WHEELCHAIR WEIGHT LIMIT
M91 Standard Up to 300 lbs
M91 Heavy Duty Up to 400 lbs

Invacare Pronto M91 Specifications

Power and Performance

maximum speed	6.5 mph / 4.5 mph
incline capability	9˚
weight capacity	300 lb. (400 lb. option)

Wheel and Caster Sizes

front casters	6" x 2"
drive wheels	14" x 3"
rear casters	6" x 2"

Weight and Dimensions

length with footboard up	39"
length with footboard down	40" - 42"
width excluding joystick	25.9"
height	37" - 48"
seat width	18" - 22"
seat depth	16" - 20"
overall height	37" - 40"
back height	18"
seat-to-floor height	21" - 23"
weight with batteries	273 lb.
weight without batteries	199 lb.
wheelchair mass	275 lb.
turning radius front	19.5"
turning radius rear	21.5"
ground clearance	3.25"
