Invacare Pronto M91 - Securing the Occupant; Wheelchair-Anchored Belts

SECTION 14—TRANSPORT READY PACKAGE (TRRO)
Part No. 1125038 127 Pronto
®
M91™and M94™
Securing the Occupant
Wheelchair-Anchored Belts
 WARNING
The pelvic belt that is provided by Invacare has been tested for use in a motor vehi-
cle on this wheelchair ONLY. DO NOT replace the pelvic belt with a different style
pelvic belt.
NOTE:Forthisprocedure,refertoFIGURE 14.2.
Thewheelchairhasbeenprovidedwithapelvicbeltwhichmeetstherequirementsof
ANSI/RESNAW/C19.
Thepelvicbelt,providedbyInvacare,hasbeendesignedtoaccommodateuseoneither
sideofthevehicle.Ifnecessary,followtheinstructionsbelowtoreversethe
orientationof
thepelvicbelttoaccommodatethevehicle‐anchoredupper‐torsobelt.
1. Installthepelvicbeltpin(Detail“A”ofFIGURE 14.2)intothelargeendoftheslotin
thebeltmountingbracket.Rotatedownwardandforwarduntilitsnapsintoplaceinto
thesmallendoftheslot.
NOTE:
Notethepositionofthemaleendofthebeltwheninstallingthepelvicbeltontothebelt
mountingbrackets.Themaleendofthepelvicbelt(DetailʺAʺofFIGURE 14.2)hasapinwhich
isusedtosecurethevehicle‐anchoredupper‐torsobelt.
2. RepeatSTEP1fortheoppositebeltmountingbracket.
3. Installthevehicle‐anchoredupper‐torsobeltontothepinonthemaleendofthepelvic
belt.
FIGURE 14.2 Wheelchair-Anchored Belts
Pin
Pin
Pin
(Used to secure the vehicle
anchored upper-torso belt)
Male End
DETAIL “A”
Back Angle
Bracket
Large End
of Slot
Belt Mounting
Bracket
Small End of Slot
Pelvic Belt
