Invacare Pronto M91 Service Manual

SECTION 6—FRONT RIGGINGS
Pronto
®
M91™and M94™ 72 Part No. 1125038
Adjusting Footrest Height
Model PHWH93
NOTE:Forthisprocedure,refertoFIGURE 6.2.
1. Removeanyaccessoriesfromthefootrest(s).
2. Removethefootrestfromthe
wheelchair.RefertoInstalling/
RemovingFrontRiggingsonpage 71.
NOTE:Layfootrestonaflatsurfacetosimplify
performingprocedure.
3. Removethehexbolt,covedwashers
andlocknutthatsecurethelower
footresttothefootrestsupport.
4. Repositionthelowerfootresttothe
desiredheight.
5. Reinstallhexbolt,covedwashersand
locknutthatsecurelowerfootrestto
footrestsupport.Tightensecurely.
FIGURE 6.2 Adjusting Footrest Height -
Model PHWH93
6. RepeatSTEPS1‐5fortheoppositefootrest,ifnecessary.
7. Reinstallthefootrest(s)ontothewheelchair.RefertoInstalling/RemovingFront
Riggingsonpage 71.
8. Reinstallanyaccessoriesontothefootrest(s).
Model PH904A and PHAL4A
NOTE:Forthispr ocedur e,refertoFIGURE 6.3.
NOTE:PH904Astylefrontriggingshown.
PHAL4Afrontriggingadjuststhesameway.
1. Loosen,butdonotremovethelugbolt
andlocknutthatsecurethelower
footresttothefootrestsupport.
2. Repositionthelowerfootresttothe
desiredheight.
3. Securelytightenthelugboltand

locknutthatsecurethelowerfootrestto
thefootrestsupport.
FIGURE 6.3 Adjusting Footrest Height -
Model PH904A and PHAL4A
4. RepeatSTEPS1‐3fortheoppositefootrest,ifnecessary.
Coved Washer
Hex Bolt
Footrest
Support
Coved
Washer
Locknut
Lower
Footrest
Locknut
Footrest
Support
Lower
Footrest
Lug Bolt

Invacare Pronto M91 Specifications

Power and Performance

maximum speed	6.5 mph / 4.5 mph
incline capability	9˚
weight capacity	300 lb. (400 lb. option)

Wheel and Caster Sizes

front casters	6" x 2"
drive wheels	14" x 3"
rear casters	6" x 2"

Weight and Dimensions

length with footboard up	39"
length with footboard down	40" - 42"
width excluding joystick	25.9"
height	37" - 48"
seat width	18" - 22"
seat depth	16" - 20"
overall height	37" - 40"
back height	18"
seat-to-floor height	21" - 23"
weight with batteries	273 lb.
weight without batteries	199 lb.
wheelchair mass	275 lb.
turning radius front	19.5"
turning radius rear	21.5"
ground clearance	3.25"
