INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-152-
Function
code
Name
Description
Default
Modify
P07.01
Parameter copy
Range: 0–4
0: No operation
1: Upload parameters to the keypad
2: Download parameters (including motor
parameters)
3: Download non-motor parameters
4: Download motor parameters
0
◎
P07.02
Key function
selection
Range: 0x00–0x27
Ones place: Function of QUICK/JOG
0: No function
1: Jog
2: Reserved
3: Switch between forward and reverse rotating
4: Clear the UP/DOWN setting
5: Coast to stop
6: Switch command channels in sequence
7: Reserved
Tens place: Reserved
0x01
◎
P07.03
Sequence of
switching
running-comman
d channels by
pressing QUICK
When P07.02=6, set the sequence of switching
running-command channels by pressing this key.
0: Keypad→Terminal→Communication
1: Keypad←→Terminal
2: Keypad←→Communication
3: Terminal←→Communication
0
○
P07.04
Stop function
validity of
STOP/RST
Used to specify the stop function validity of
STOP/RST. For fault reset, STOP/RST is valid
in any conditions.
0: Valid only for keypad control
1: Valid both for keypad and terminal control
2: Valid both for keypad and communication
control
3: Valid for all control modes
0
○
P07.05–P
07.07
Reserved
P07.08
Frequency
display
coefficient
0.01–10.00
Display frequency = Running frequency * P07.08
1.00
○
P07.09
Rotational speed
display
coefficient
0.1–999.9%
Mechanical rotation speed = 120 * (Displayed
running frequency) * P07.09/(Motor pole pairs)
100.0%
○
