INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-81-
Function
code
Name
Description
Default
communication
22: Torque current (bipolar, 100%
corresponding to 10V)
23: Exciting current (100% corresponding to
10V)
24: Set frequency (bipolar)
25: Ramp reference frequency (bipolar)
26: Rotational speed (bipolar)
27: Value 2 set through EtherCAT/Profinet
communication
28: C_AO1 from PLC (Set P27.00 to 1.)
29: C_AO2 from PLC (Set P27.00 to 1.)
30: Rotational speed
31–47: Reserved
P06.17
AO1 output lower limit
-300.0%– P06.19
0.0%
P06.18
AO1 output
corresponding to lower
limit
0.00V–10.00V
0.00V
P06.19
AO1 output upper limit
P06.17–100%
100.0%
P06.20
AO1 output
corresponding to upper
limit
0.00V–10.00V
10.00V
P06.21
AO1 output filter time
0.000s–10.000s
0.000s
P06.22–P
06.26
Reserved
0–65535
0
P06.27
HDO output lower limit
-300.0%– P06.29
0.0%
P06.28
HDO output
corresponding to lower
limit
0.00–50.00Hz
0.0kHz
P06.29
HDO output upper limit
P06.27–100%
100.0%
P06.30
HDO output
corresponding to upper
limit
0.00–50.00Hz
50.00kHz
P06.31
HDO output filter time
0.000s–10.000s
0.000s
