RJ-45 Management Port Connector Pinout Information
Table 44 on page 93 provides the pinout information for the RJ-45 connector for the
management port on Juniper Networks devices.
Table 44: RJ-45 Management Port Connector Pinout Information
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1-2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3-5
Transmit/receive data pair 2TRP2-6
Transmit/receive data pair 4TRP4+7
Transmit/receive data pair 4TRP4-8
Related
Documentation
Connecting a Device to a Network for Out-of-Band Management on page 157•
93Copyright © 2017, Juniper Networks, Inc.
Chapter 9: Pinout Specifications
