Figure 51: Connecting a Fiber-Optic Cable to an Optical Transceiver

Installed in a Device

4. Secure the cables so that they do not support their own weight. Place excess cable

out of the way in a neatly coiled loop. Placing fasteners on a loop helps cables maintain

their shape.

CAUTION: Do not bend fiber-optic cables beyond their minimum bend

radius.An arc smallerthan afew inches in diameter candamage the cables

and cause problems that are difficult to diagnose.

Do not let fiber-optic cables hang free from the connector. Do not allow

fastened loops of cables to dangle, which stresses the cables at the

fastening point.

Documentation

• Disconnecting a Fiber-Optic Cable from a Device on page 200

• Installing a Transceiver on page 193

• Maintaining Fiber-Optic Cables on page 201
