Mounting an EX4200 Switch on a Wall
You can mount an EX4200 switch on a wall byusing theseparately orderable wall-mount
kit.
Before mounting the switch on a wall:
•
Verify that the site meets the requirements described in “Site Preparation Checklist
for EX4200 Switches” on page 61.
•
Read “General Safety Guidelines and Warnings” on page 243, with particular attention
to “Chassis Lifting Guidelines” on page 252.
•
Remove the switch from the shipping carton (see “Unpacking an EX4200 Switch” on
page 121).
Ensure that you have the following parts and tools available:
•
Phillips (+) screwdriver, number 2
•
2 wall-mount brackets (provided with the wall-mount kit)
•
12 wall-mount bracket screws (provided with the wall-mount kit)
•
4 mounting screws (8-32 x 1.25 in. or M4 x 30 mm) (not included)
•
Dust covers for ports (for EX4200-24F switches only; optional)
•
Hollow wall anchors capable of supporting the combined weight of two fully loaded
switches, up to 44 lb (20 kg) (not included)—if you are mounting the switch in sheetrock
(wall board with a gypsum plaster core) or in wall board not backed by wall studs
WARNING: When mounted in a vertical position, an EX4200 switch must be
oriented with the front panel of the chassis pointing down in order to ensure
proper airflow and meet safety requirements in the event of a fire.
NOTE: For easier lifting, install any additional power supplies only after you
mount the switch on the wall.
To mount the switch on a wall:
Copyright © 2017, Juniper Networks, Inc.138
