Table 18: Health Status (continued)
DescriptionField
Indicates the memory used in the external Routing Engine. In an EX8200 Virtual Chassis,thememory
utilization value of the XRE200 External Routing Engine in the master role is displayed. Click the
XRE200 External Routing Engine in the backup role to view the memory used in the backup external
Routing Engine.
Memory util.
Indicates the average CPU usage over 15 minutes.CPU load
Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash
XRE200 External Routing Engines
Indicates the memory used in the external Routing Engine. In an EX8200 Virtual Chassis,thememory
utilization value of the XRE200 External Routing Engine in the master role is displayed. Click the
backup XRE200 External Routing Engine to view the memory used in backup external Routing Engine.
Memory util.
Indicates the average CPU usage over 15 minutes.CPU load
Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash
Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent.Fan Status
Capacity Utilization Panel
Table 19: Capacity Utilization
DescriptionField
Indicates the number of active ports in the switch. Configured
Virtual Chassis ports (VCPs) are considered as active ports.
Number of active ports
Indicates the number of ports in the switch.
NOTE: In EX3300 and EX4600 Virtual Chassis, the total
number of ports of all of the switches is displayed.
Total number of ports
Indicates the number of MAC table entries.Used-up MAC-Table entries
Indicates the maximum number of MACtable entries permitted.Supported MAC-Table entries
Indicates the number of VLANs configured.
NOTE: Only tagged VLANs are counted.
Number of VLANs configured
Indicates the maximum number of VLANs supported.Number of VLANs supported
Alarms Panel
Displays information about the last five alarms raised in the system. For example, if there
are 5 major alarms, then details of all 5 major alarms are displayed. If there are 4 major
45Copyright © 2017, Juniper Networks, Inc.
Chapter 5: Viewing System Information
