Table 20: Chassis Viewer for EX2200 Switches (continued)
DescriptionField
The management port is used to connect the switch to a management device for out-of-band
management.
Management (me0) port
The console port is used to connect the switch to a management console or to a console
server. (You might do this for initial switch configuration.)
Console port
Indicates the USB port for the switch.
NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for
your EX Series switch.
USB port
Mouse over the fan tray icon to display name, status, and description information.Fan tray
Mouse over the power outlet icon to display name, status, and description information.Power supply
Table 21: Chassis Viewer for EX2200-C Switches
DescriptionField
Front View
In the image, the following colors denote the interface status:
•
Green—Interface is up and operational.
•
Yellow—Interface is up but is nonoperational.
•
Gray—Interface is down and nonoperational.
Mouse over the interface (port) to view more information.
Interface status
The management port is used to connectthe switch to a management device for out-of-band
management.
Management (me0) port
The console port is used to connect the switch to a management console or to a console
server. (You might do this for initial switch configuration.)
Console port
Indicates the USB port for the switch.
NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for
your EX Series switch.
USB port
Rear View
Mouse over the power outlet icon to display name, status, and description information.Power supply
Table 22: Chassis Viewer for EX3200, EX3300, and EX4200 Switches
DescriptionField
Front View
