CAUTION: Ensure the screwdriver does not slip out of the keyhole when
you pull the uplink module out of the switch chassis.
4. Using both hands, gently pull the screwdriver to slide the uplink module halfway out
of the chassis (see Figure 60 on page 191).
5. Place one hand under the uplink module to support it and slide it completely out of
the chassis.
6. Slide the screwdriver out of the keyhole.
7. Place the uplink module in an antistatic bag or on an antistatic mat placed on a flat,
stable surface.
Figure 59: Sliding the Screwdriver to the Narrow Part of the Keyhole
Figure 60: Removing an Uplink Module from an EX4200 Switch
191Copyright © 2017, Juniper Networks, Inc.
Chapter 18: Replacing Uplink Module
