PIC 2 BUILTIN BUILTIN 1x 10GE XFP
Xcvr 0 REV 01 740-014279 K9J03BF XFP-10G-LR
PIC 3 BUILTIN BUILTIN 1x 10GE XFP
Xcvr 0 REV 01 740-014279 K9J02UB XFP-10G-LR
Fan Tray Fan Tray
Most components also have a small rectangular serial number ID label (see
Figure 57 on page 135) attached to the component body.
Figure 57: Serial Number ID Label
MX5, MX10, MX40, and MX80 Chassis Serial Number Label
The chassis serial number is located on the rear of the chassis (see Figure 58 on page 135).
Figure 58: MX5, MX10, MX40, and MX80 Chassis Serial Number Label
g005021
CLOCK
SYNC
Serial number
ID label
MX5, MX10, MX40, and MX80 Fan Tray Serial Number Label
The serial number label is located on the top of the fan tray toward the front (see
Figure 59 on page 135).
Figure 59: MX5, MX10, MX40, and MX80 Fan Tray Serial Number Label
g005045
Serial number ID label
135Copyright © 2019, Juniper Networks, Inc.
Chapter 6: Contacting Customer Support and Returning the Chassis or Components
