Table 9: Link LEDs on the Front Panel
DescriptionStateColorLabel
Link is up.On steadilyGreenLINK
No link.Off–
Routing Engine LED on the Front Panel
One LED on the left side of the front panel indicates the status of the Routing Engine.
The LED is located below the RE label. Table 10 on page 31 describes the Routing Engine
LED in more detail.
Table 10: Routing Engine LED on the Front Panel
DescriptionStateColorLabel
Routing Engine is transitioning online.BlinkingGreenLINK
Routing Engine has failed.BlinkingRed
Routing Engine is functioning normally.Off–
System LED on the Front Panel
One LED on the left side of the front panel indicates the status of the router. The LED is
located below the SYS OK label. Table 11 on page 31 describes the system LED in more
detail.
Table 11: System LED on the Front Panel
DescriptionStateColorLabel
Routing Engine is functioning normally.On steadilyGreenSYS OK
Routing Engine is transitioning online.Off—
See Also Troubleshooting Resources for MX5, MX10, MX40, and MX80 Routers on page 127•
• Troubleshooting the MX5, MX10, MX40, and MX80 Fan Tray on page 129
• Troubleshooting the MX5, MX10, MX40, and MX80 MICs on page 130
• Troubleshooting the MX5, MX10, MX40, and MX80 Power Supplies on page 130
MX5, MX10, MX40, and MX80 Power System
•
MX5, MX10, MX40, and MX80 Power System Description on page 32
•
MX5, MX10, MX40, and MX80 Power Supply LED on page 34
31Copyright © 2019, Juniper Networks, Inc.
Chapter 1: Overview
