Table 7: MX5, MX10, MX40, and MX80 Routers Hardware Components and CLI Terminology (continued)
DescriptionCLI NameHardware Model NumberComponent
MX5, MX10, MX40, and MX80
Cooling System Description
Cooling system, including fan trays and air filters
N/AFLTR-KIT-MX80Air filter kit
Fan TrayFANTRAY-MX80Fan tray
“MX5, MX10, MX40, and MX80
Power System Description” on
page 32
Power system components
N/APWR-BLANK-MX80Power blank cover
PEM
•
AC: PWR-MX80-AC
•
DC: PWR-MX80-DC
Power supply
“MX5, MX10, MX40, and MX80
Modular Interface Card Description”
on page 43
See MX Series Interface Module Reference.
MIC
“MX5, MX10, MX40, and MX80
Modular Interface Card Description”
on page 43
FPCN/A (built-in)MPC
“MX5, MX10, MX40, and MX80
Routing Engine Description” on
page 42
Routing EngineN/A (built-in)Routing Engine
Xcvr
See MX Series Interface
Module Reference.
Transceiver
MX5, MX10, MX40, and MX80 Chassis
•
MX5, MX10, MX40, and MX80 Chassis Description on page 24
•
MX5, MX10, MX40, and MX80 Baseboard Description on page 26
•
MX5, MX10, MX40, and MX80 Cable Management Bracket Description on page 27
•
MX5, MX10, MX40, and MX80 Front Panel Description on page 28
•
Alarm LEDs on the MX5, MX10, MX40, and MX80 Front Panel on page 30
•
Component LEDs on the MX5, MX10, MX40, and MX80 Front Panel on page 30
MX5, MX10, MX40, and MX80 Chassis Description
The router chassis is a rigid sheet metal structure that houses all the other router
components (see Figure 5 on page 25, Figure 6 on page 25, Figure 7 on page 25,
Figure 8 on page 26, Figure 9 on page 26, and Figure 10 on page 26). The chassis measures
3.5 in. (8.9 cm) high, 17.5 in. (44.5 cm) wide, and 23.46 in. (59.6 cm) deep. The chassis
installs in standard 600-mm deep (or larger) enclosed cabinets, 19-in. equipment racks,
or telco open-frame racks.
Copyright © 2019, Juniper Networks, Inc.24
MX5, MX10, MX40, and MX80 Universal Routing Platforms Hardware Guide
