Juniper MX5 Hardware Guide

Table 38: Cable Specifications for Routing Engine Management (continued)
Router
Receptacle
Maximum
Length
Cable/Wire
Supplied
Cable
SpecificationPort
RJ-45
autosensing
328 ft (100 m)One 15-ft
(4.57-m) length
with
RJ-45/RJ-45
connectors
Category 5 cable
or equivalent
suitable for
100Base-T
operation
Routing Engine
Ethernet
interface
See Also MX5, MX10, MX40, and MX80 Routing Engine Description on page 42•
• Maintaining the MX5, MX10, MX40, and MX80 Routing Engine on page 97
MX5, MX10, MX40, and MX80 Management, and Console Port Specifications and
Pinouts
•
RJ-45 Connector Pinouts for the AUX and CONSOLE Ports on MX5, MX10, MX40, and
MX80 Routers on page 72
•
RJ-45 Connector Pinouts for the ETHERNET Port on MX5, MX10, MX40, and MX80
Routers on page 73
RJ-45 Connector Pinouts for the AUX and CONSOLE Ports on MX5, MX10, MX40, and MX80
Routers
The ports on the front panel labeled AUX and CONSOLE are asynchronous serial interfaces
that accept an RJ-45 connector. The ports connect the Routing Engine to an auxiliary or
console management device. Table 39 on page 72 describes the RJ-45 connector pinout.
Table 39: RJ-45 Connector Pinout for the AUX and CONSOLE Ports
DescriptionSignalPin
Request to SendRTS1
Data Terminal ReadyDTR2
Transmit DataTXD3
Signal GroundGround4
Signal GroundGround5
Receive DataRXD6
Data Set ReadyDSR/DCD7
Clear to SendCTS8
Copyright © 2019, Juniper Networks, Inc.72
MX5, MX10, MX40, and MX80 Universal Routing Platforms Hardware Guide
