Juniper SRX110 Hardware Guide

The dual-root partitioning scheme keeps the primary and backup Junos OS images in
two independently bootable root partitions. If the primary root partition becomes
corrupted, the system can boot from the backup Junos OS image in the other root partition
and remain fully functional.
When the SRX110 Services Gateway powers up, it tries to boot Junos OS from the default
storage medium. If the device fails to boot from the default storage medium, it tries to
boot from the alternate storage medium. With the dual-root partitioning scheme, the
services gateway first tries to boot Junos OS from the primary root partition and then
from the backup root partition on the default storage medium. If both primary and backup
root partitions of a storage medium fail to boot, then the device tries to boot from the
next available type of storage media. The services gateway remains fully functional even
if it boots Junos OS from the backup root partition of the storage medium.
Related
Documentation
SRX110 Services Gateway Front Panel and Back Panel Views with 3G and Integrated
VDSL2 on page 9
•
• SRX110 Services Gateway LEDs on page 13
• SRX110 Services Gateway Power Supply on page 16
• SRX110 Services Gateway Specifications on page 7
SRX110 Services Gateway Power Supply
The power supply for the SRX110 Services Gateway is external. You must use the power
supply adapter provided by Juniper Networks to provide power to the services gateway.
Figure 8 on page 16 shows the label for the 12 V power supply.
Figure 8: SRX110 Services Gateway — 12 V Power Supply
g033607
Copyright © 2013, Juniper Networks, Inc.16
SRX110 Services Gateway Hardware Guide
