Juniper SRX110 Hardware Guide

Table 19: SRX110 Services Gateway Cabinet Requirements (continued)
SpecificationsCabinet Requirement
•
The cabinet is at least 1 U (1.75 in. or 4.5 cm) high.
•
The outer edges of the mounting brackets extend the width
of either chassis to 19 in. (48.2 cm), and the front of the
chassis extends approximately 0.5 in. (1.27 cm) beyond the
mounting brackets.
•
The minimum total clearance inside the cabinet is 30.7 in.
(78 cm) between the inside of the front door and the inside
of the rear door.
NOTE: The holes for the mounting brackets for the chassis
are spaced 1.25 in. (3.2 cm) apart, measured from the center
of the hole.
Clearance
•
Ensure that ventilation through the cabinet is sufficient to
prevent overheating.
•
Ensure that cool air supply is adequate to dissipate the
thermal output of the device.
•
Install the device as close as possible to the front of the
cabinet so that the cable management system clears the
inside of the front door. Installing the chassis close to the
front of the cabinet maximizes the clearance at the rear of
the cabinet for critical airflow.
•
Route and dress all cables to minimize the blockage of
airflow to and from the chassis.
NOTE: A cabinet larger than the minimum required size
provides better airflow and reduces the chance of overheating.
Airflow
Related
Documentation
General Site Guidelines for Installing the SRX110 Services Gateway on page 40•
• SRX110 Services Gateway Rack Requirements on page 41
• Clearance Requirements for Airflow and Hardware Maintenance of the SRX110 Services
Gateway on page 42
SRX110 Services Gateway Rack Requirements
The services gateway can be installed in a rack. Many types of racks are acceptable,
including front-mount racks and four-post (telco) racks.
NOTE: The services gateway cannot be center mounted in a rack.
Table 20 on page 42 provides the details of requirements for rack size, clearance, airflow,
spacing of mounting brackets and flange holes, and connecting to the building structure.
41Copyright © 2013, Juniper Networks, Inc.
Chapter 5: Preparing the Site for the SRX110 Services Gateway Installation
