KYMCO XCITING 500 Service Manual

1. GENERAL INFORMATION
1-9
XCITING 500
FRAME (Cont’d)
Item Q‘ty Thread dia.(mm)
Torque
N•m (kgf•m,
lbf•ft)
Remarks
ENGINE HANGER:
Engine hanger bolt
Engine mounting bolt
Engine mounting nut
Engine hanger rod nut
MUFFLER
Exhaust pipe nut
Muffler mount bolt
4
1
1
1
2
3
10
14
14
10
8
10
50 (5, 36)
80 (8, 58)
80 (8, 58)
35 (3.5, 25)
20 (2, 14)
35 (3.5, 25)
SPECIAL TOOLS
Tool Name Tool No. Remarks
Clutch spring compressor
E053 Clutch disassembly
Bearing puller 10,12,15,18mm E037
Bearing removal
Valve spring compressor E040
Valve removal
Oil seal & bearing installer E014
Oil seal & bearing install
Tappet adjuster E036
Tappet adjustment
Flywheel puller E054
A.C. generator flywheel removal
Universal holder E017
Holding clutch for removal
Oil filter cartridge wrench E052
Cartridge removal or install
Flywheel holder E021
A.C. generator flywheel holding
Lock nut socket wrench F002
Steering stem removal or install

KYMCO XCITING 500 Specifications

General

Displacement	499 cc
Cooling System	Liquid-cooled
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shocks
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	800 mm
Tire (Front)	120/70-15
Tire (Rear)	150/70-14
Engine Type	4-stroke, single-cylinder
Fuel System	Electronic Fuel Injection
Fuel Capacity	12.8 L
Length x Width x Height	2250 x 800 x 1450 mm
