KYMCO XCITING 500 Service Manual

1. GENERAL INFORMATION
1-10
XCITING 500
LUBRICATION POINTS
ENGINE
Lubrication Points Lubricant
Valve guide/valve stem movable part
Camshaft protruding surface
Valve rocker arm friction surface
Camshaft drive chain
Cylinder lock bolt and nut
Piston surroundings and piston ring grooves
Piston pin surroundings
Cylinder inside wall
Connecting rod/piston pin hole
Connecting rod big end
Crankshaft
Balancer shaft
Crankshaft one-way clutch movable part
Oil pump drive chain
Starter reduction gear engaging part
O-ring face
Oil seal lip
•Genuine KYMCO Engine Oil (SAE 5W-50)
•API SJ Engine Oil
Drive gear shaft
Countershaft
Final gear
Final gear shaft
Transmission gearshaft bearing part
Transmission oil: SAE 90
A.C. generator connector Adhesive

KYMCO XCITING 500 Specifications

General

Displacement	499 cc
Cooling System	Liquid-cooled
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shocks
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	800 mm
Tire (Front)	120/70-15
Tire (Rear)	150/70-14
Engine Type	4-stroke, single-cylinder
Fuel System	Electronic Fuel Injection
Fuel Capacity	12.8 L
Length x Width x Height	2250 x 800 x 1450 mm
