KYMCO XCITING 500 Service Manual

15. REAR FORK/REAR WHEEL/
REAR SHOCK ABSORBER
15-0
XCITING 500
15
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
REAR FORK/REAR WHEEL/
REAR SHOCK ABSORBER
__________________________________________________________________________________
SCHEMATIC DRAWING ------------------------------------------------- 15- 1
SERVICE INFORMATION------------------------------------------------ 15- 2
TROUBLESHOOTING----------------------------------------------------- 15- 3
REAR WHEEL/REAR FORK --------------------------------------------- 15- 4
REAR SHOCK ABSORBER ---------------------------------------------- 15-10
15

KYMCO XCITING 500 Specifications

General

Displacement	499 cc
Cooling System	Liquid-cooled
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shocks
Front Brake	Dual disc
Rear Brake	Single disc
Seat Height	800 mm
Tire (Front)	120/70-15
Tire (Rear)	150/70-14
Engine Type	4-stroke, single-cylinder
Fuel System	Electronic Fuel Injection
Fuel Capacity	12.8 L
Length x Width x Height	2250 x 800 x 1450 mm
